2015 ManRoland 708 Ultima LTT-8-LV

Equipped with the following:

HiPrint Series LTT-DDDDDDDD-LV
Max sheet size: 740 x 1040 mm
Min sheet size: 340 x 480 mm
Max image area: 715 x 1020 mm
Printing plate size: 785 x 1030 mm
Printing plate thickness: 0.28 mm
Stock thickness: 0.04 – 1.0 mm
Press Speed: 16,000 s/h\
Electrical equipment of the machine designed for North America, frequency 60 Hz (TUV/SUD)
Lightning and overvoltage protection
ManRoland EnergyLink- Powervar Unit
Air supply unit according to US standards
SelectCompressor
Printcom S blankets
Printcom roller covering
IPA free dampening rollers
Semiautomatic inspection sheet removal with preselection of the number of inspection sheets (1 to 15 sheets)
Four (4) Pile board with feet
Oil change pump
SelectPowderSystem, powdering device Grafix Powdermax Perfect
Manual nonstop device in feeder
Semiautomatic nonstop operation in delivery
SelectCombiCenter – LS combination device
External condenser
Telepresence with integrated maintenance manager
IntegrationPilot plus 2.0
ProcessMonitor
One (1) InlineColorPilot color density and control system
SpectroDrvie motorized measuring device for colormetric measurement
ColorPilot D + F – densitometry and colorimetry
PressPilot Comfort package
Inline Register for InlineColorPilot
Control console operation on printing unit 1
SmartCard printing performance package
SelectAntiStatic plus ionization system, manufactured by Eltex
QuickStart Plus
QuickChange Surface
QuickChange Wash
QuickChange Job Plus
QuickChange Infeed
QuickChange Air
QuickChange Color Plus
Triple flow inker
Low Coverage Stabilization
APL – automatic plate loading system
Disengagable inking units on all printing units
Double coating modules
Two transfer modules
Extended Delivery
QuickChange Coating smart
QuickChange Coating, system for quick coating change in coating modules
QuickChange Clamp
Fine correction of the printing pressure adjustment between the form cylinder and impression cylinder of the coating module
SelectCleaningSystem, Brush wash-up device
Automatic rubber blanket wash-up device
Intercom at the feeder and delivery
Height Parts 21.66” (550 MM)
Ink mist removal unit with an integrated ink mist removal unit
preparation of the press for Interdeck and end of press UV
SelectDryer UV Drying system
Print&Wash – omission of the UV dryer-related waiting time
Inking and Dampening rollers for exclusive use of UV inks
Inking and dampening rollers for UV and Conventional inks in Printing Unit 1
Two(2) mechanical double sheet controls
Sunk pile supporting plate with border frame at the feeder and delivery
Blowers under the feed board
Accel Sentinel ink management system, without console
C. 51 M Imp
